Networked I/O

Compatible with Trio's own high speed CANbus or third party masters with CANOpen DS401
16-Out Digital module
16-In Digital module16-In/Out Digital module
8-In/4-Out Analog module
8-Out relay module

Use with Trio or 3rd Party EtherCAT Masters
High performance, flexible topology and simple configuration
Bus cycle time synchronised with Motion Coordinator Servo Period
Bus coupler module with 2 x RJ45 Ethernet ports for EtherCAT connection
16-Out PNP, 16-In PNP, 3 Axis Step Pulse, 16-Out NPN, 16-In NPN, 8 Analog Out, 8 Analog In modules
EtherCAT protocol remains fully intact down to individual modules using the EBUS system
I/O functions tightly synchronised to motion using EtherCAT distributed clocks
Automatic mapping to the Motion Coordinator I/O system
DIN rail mounted
Multiple practical push-in connector options – No break outs required
Clip-together design with ‘quick release’ locks for mechanical integrity
User labelling facility
Machine builder custom functionality options
